In a pultruded profile the glass fibres carry the load, but the resin decides how long the profile keeps doing it: it protects the fibres from water, chemicals and UV, transfers load between fibres, and sets the temperature and fire behaviour. This guide replaces three earlier, overlapping resin articles on this site and is organised around the decision you actually have to make.
Step 1: Answer three questions about the environment
- What touches the profile? Fresh water or humidity only, de-icing salt or seawater, or process chemicals (acids, alkalis, solvents)? Name the chemical and its concentration, not just "corrosive".
- How hot does it get? Use the highest continuous temperature in service, plus any short peaks. A common rule of thumb is to keep peak operating temperature at least about 20 °C below the resin’s heat distortion temperature (HDT) – check the datasheet of the exact grade.
- Do fire, smoke or electrical insulation requirements apply? Tunnels, transit, offshore and high-voltage work are usually governed by a standard, so the resin choice follows the standard.
Step 2: Match the answers to a resin family
| Resin family | Where it is strong | Limits to know | Typical use |
|---|---|---|---|
| Orthophthalic polyester | Lowest cost, fast to process, good for dry, mild conditions. | Moderate water and chemical resistance. | Indoor structural parts, cladding, general profiles. |
| Isophthalic polyester | Better water and chemical resistance and toughness than ortho; the usual all-round choice. | Not for constant strong acid or alkali. | Cooling towers, walkways, outdoor structures (with UV stabiliser and surface veil). |
| Vinyl ester | Much better resistance to hydrolysis, acids and alkalis; tougher under cyclic load. | Higher cost than polyester. | Wastewater and chemical plants, marine and coastal structures, sheet piling in saline ground. |
| Phenolic | Chars rather than burns; very low smoke and toxic fume; built for FST (fire, smoke, toxicity) requirements. | Lower toughness; usually the most demanding to process. | Tunnels, mass transit, offshore grating where the standard requires it (e.g. EN 45545, ASTM E84 Class A). |
| Epoxy | Excellent adhesion to fibre, low shrinkage, high electrical performance. | Slower cure and higher cost; far less common in standard pultrusion. | Electrical insulation rods, high-performance structural parts. |
Step 3: Check the things the resin does not fix
- UV and "fibre bloom". The white, fibrous look of a weathered surface is controlled mainly by UV stabilisers and a resin-rich surface veil, not by switching resin family alone.
- Fire performance. Polyester or vinyl ester can be made flame-retardant with fillers such as alumina trihydrate (ATH); phenolic is the route when smoke and toxicity limits are strict. Ask which standard and class you must meet.
- Colour. Polyester and vinyl ester take integral pigment easily; epoxy can need UV-stable pigment systems to avoid yellowing.
- Anti-static or conductive profiles. These come from additives, not from the base resin, and are specified separately for explosive or electronics environments.
Worked selection examples
| Application | Environment | Sensible starting point |
|---|---|---|
| Walkway beside a cooling tower | Constant humidity, treated water, moderate temperature | Isophthalic polyester, UV-stabilised, surface veil |
| Baffles in a wastewater plant | Wet, hydrogen sulphide, mild acids | Vinyl ester |
| Sheet piling and seawall in saline ground | Chlorides, continuous moisture | Vinyl ester is the usual choice for this exposure; ask which resin applies to our Type U sheet piling or Type Z seawall for your conditions |
| Cable tray in a metro tunnel | Fire, smoke and toxicity rules apply | Phenolic, or the resin the project standard names |
| Indoor machine frame | Dry, ambient temperature | Orthophthalic or isophthalic polyester |
These are starting points for a conversation, not a guarantee: the final grade depends on the exact chemical, concentration and temperature, and on the standard you must meet.
Frequently asked questions
Can UV-stabilised polyester replace vinyl ester outdoors?
For sunlight and rain alone, yes. If the same profile is also exposed to acid or salt, vinyl ester is the safer choice.
Why is epoxy uncommon in standard pultrusion?
Epoxy cures more slowly and is more expensive to process on a pultrusion line, so it is normally reserved for specialist electrical or high-performance parts.
Can two resins be combined in one profile?
Generally no. Each family has its own shrinkage and cure behaviour, and mixing them in one section risks poor bonding. Different parts of an assembly can use different resins.
Is there a bio-based or recycled option?
Resins with bio-based content exist, but performance varies by product. Ask for the datasheet and test data of the specific grade before substituting.
Related: what we need to know before quoting a custom profile and how the pultrusion process works.
